| Max.output (kgf) |
Stroke of
spin head (mm) |
Riveting capacity
(Mild steel rivet) (mm) |
Distance between
punch and table (mm) |
Depth of
throat (mm) |
AC Motor
rating 4 Poles 3 Phase |
Cam Index 70DFO-8N | Automatic unloading |
| 1980 | 0-45 |
Solid 3 - 12
Hollow 2 - 20 |
78 | 100 | Spindle 1 HP Pump 2 Hp | 8 Position | By Blowing |
| Gauge pressure (kgf/cm 2) | Timer control (second) | Work table W (mm) | Dimension LxWxH (mm) | N.W.(kgs) | Wooden case LxWxH (mm) | G.W. (kgs) | Cooling System |
| 10 - 70 | 0.5 - 6 | 450 | 1220x520x1800 | 508 | 1310x630x1980 | 600 | By air |
